    Ductile Iron Industrial Water Strainers Straight Flow Design

    Ask Lasest Price
    Brand Name : OEM
    Model Number : YS
    Certification : WRAS/ ISO 9001
    Price : negotiation
    Payment Terms : T/T advance or L/C at sight
    Supply Ability : 90,000pcs per month
    Delivery Time : 1usually within 35 days after received your payment
    • Product Details
    • Company Profile

    Ductile Iron Industrial Water Strainers Straight Flow Design

    Ductile Iron Industrial Water Strainers Straight Flow Design


    Straight Flow Strainer is mainly installed inlet of water meter or other equipments, which can improve the clearance in the medium, and prolong the life of valves and other equipments.

    Feature:

    Quick open cover
    Straight through flow design
    Low pressure loss
    Quick and easy to service
    Nominal Pressure: 1.0~1.6 MPa
    Sizes: DN50-200


    Straight Flow Strainer is mainly installed inlet of water meter or other equipments, which can improve the clearance in the medium, and prolong the life of valves and other equipments.


    Feature:


    Quick open cover


    Straight through flow design


    Low pressure loss


    Quick and easy to service


    Part Material
    NO.PART NAMEMaterial
    1BodyDuctile Iron
    2Filter MeshStainless Steel 304
    3O-RingEPDM
    4BonnetDuctile Iron

    Technical Specification
    Nominal Pressure:1.0,1.6MPa
    DN:50~200mm
    Medium: water,sewage
    Work temperature: ≤120℃
    Design Standard :BS5163
    Flange Standard :BS EN 1092
    OTHER STANDARD ARE AVAILABLE UPON REQUEST.


    Dimension Unit:mm
    DN5080100150200
    L190254305406521
    H190225256310380
