1" DIA PVC TRUE UNION Floating Ball Valve SOCKET ENDS , ASTM D 1785
Brief introduction:
1, Compact ball valve is durable in usage for long time
2 , Compact ball valve is healthy to human body, harmless
3 , Light weight and high strength
4 , No vibration noise when it's used
5 , Compact ball valve is easy to be opened and closed
6 , Compact ball valve is easy to be installed
7 , Lowest leakage rate, 100%tested before packing
8 , The fluid resistance is small
9 , Valve Material: PVC
10 , Handle material of ball valve: ABS, body material: PVC
11 , Alkali and acid resistance
12 , Soft color and execllent design
13 , Environment friendly, non-toxic
14 , Widly used in daily life: Construction, agricultural
irrigation, industry, garden, swinming pool...
15 , These ball valve are offered in sizes ranging from 20mm
to110mm(from 1/2'' to 4'')
16 , Working Pressure: 150PSI
17 , Color Available: Green, grey, white, brown, blue
18 , Certificate: ISO 9001,china test
Application: Water supply, water draining, farming, irrigation, Aquiculture, and
water treatment and other fields
ODM and OEM are welcome.
Feature:
Full-Flow, Excellence Appearance, High-Strength, Corrosion
Resistance, Long Life
PTFE Ball Seat Seal, Low Torque
The Valve Base Can be Adjust Elastic by Manual
Release from the Central Valve Remained Intact, Can be Replaced
Embedded Platform for the Provision of Fringe Nut Copper to
Facilitate the Installation of Automatic
Actuator
Technical Specification
Nominal pressure(Mpa) | PN | 2.5,4.0,6.4 |
Strength testing pressure(Mpa) | PT | 3.8,6.0,9.6 |
Low pressure seal test(Mpa) | | 0.6 |
High pressure seal test(Mpa) | | 3.0,4.8,7.6 |
Applicable medium | water, oil, gas, nitric acid, acetic acid |
Applicable temperature | -40～180℃ |
Feature:
- Anti-blowout Structure of Valve Stem
When medium pass through the valve, the pressure in valve body may
possibly
push the stem out, or when the valve is in repair, if there is
pressure in the middle
cavity, the stem or medium seems to easily fly out upon
disassembling the valve,
which can cause injures to human beings,
To prevent the possibilities, a dummy club is packing and thrust
bearing are burnt
or packing is damaged due to other causes, the pressure of medium
in valve body
will make the dummy club of valve stem in close contact with the
upper seal face of
valve body.
Thus to prevent medium leaking out from the damage packing
position.
- Reliable Seal Structure
The seat is made of PTFE. Because the contact area between seat and
the ball will
becomes more high with rising of pressure of the middle cavity,
Small Resistance ball valve has the smallest resistance of all the
valve, in the case
of reduced bore, the resistance is little still.
- Prompt switch
The ball valve circumrotates in 90°,It work quickly to open or
close.
Specifications:
Technical Specification
- Nominal diameter: 1/2”-25”
- Applicable Temperature: -29℃～425℃(steel) -40℃～550℃(stainless
steel)
- Nominal pressure: 150lbs, 300lbs, 600Lb,900lbs,1500lbs
PN16/25/40/64/100/160, JIS 5K /10K/20K
- Applicable Medium: water ,gas,oil,and other causticity medium.
Applications Standard
- Manufacture standard : API 608/ DIN/ BS/JIS
- Face to face dimension: ANSI B 16.10,API 6D/ DIN/ BS/JIS
- Flange dimension: ANSI B 16.5 MSS-SP-44/ DIN/ BS/JIS
- Test: API 598 API 6D/ DIN/ BS/JIS
Description:
Brief introduction:
The ball valve is designed and manufactured according well to API
608. Floating ball when small caliber,
and fixed ball when large caliber.
It has fire protection structure and antistatic device. Widely used
for petroleum, chemistry, water
treatment industries.
Features:
- Anti-blowout Structure of Valve Stem
When medium pass through the valve, the pressure in valve body may
possibly push the stem out, or
when the valve is in repair, if there is pressure in the middle
cavity, the stem or medium seems to easily
fly out upon disassembling the valve, which can cause injures to
human beings, To prevent the
possibilities, a dummy club is packing and thrust bearing are burnt
or packing is damaged due to other
causes, the pressure of medium in valve body will make the dummy
club of valve stem in close contact
with the upper seal face of valve body. Thus to prevent medium
leaking out from the damage packing
position.
- Reliable Seal Structure
The seat is made of PTFE. Because the contact area between seat and
the ball will becomes more high
with rising of pressure of the middle cavity, Small Resistance ball
valve has the smallest resistance of all
the valve, in the case of reduced bore, the resistance is little
still.
-Prompt switch
The ball valve circumrotates in 90°,It work quickly to open or
close.
